Automatic Industrial Custom Fresh Customized Juice Pulp Production Line for mango

Name: Automatic Industrial Custom Fresh Customized Juice Pulp Production Line for mango
Brand: Zhongde Food Machinery Jingjiang Co., Ltd.
Availability: InStock

Large Image : Automatic Industrial Custom Fresh Customized Juice Pulp Production Line for mango

Product Details:

Contact Now

Detailed Product Description

Overview of Mango processing line

The mango process Line is mainly composed of washer, Sort conveyor, Elevator, Crusher and Preheater / De-stoner , Pulping & Refiner, Buffer tank & pump, Evaporation, Holding tank, Sterilizer，Aseptic filler and other processes. The mango process Line is mainly used in tomatoes, mangoes, guava and other products.

Key Features of Mango processing line

● The main structure of the device is made of high-quality food-grade 304 stainless steel;
● The specifications of the equipment can be selected according to the actual needs of customers;
● The quality of the end product is good, the quality of the finished product is good, and the color is delicious;
● High production efficiency, flexible production, and can customize the production line plan according to the actual needs of customers.

Raw material	mango, tomato, guava
Final product	mango puree/jam, tomato paste, guava concentrate
Capacity	3-25t/h
Juice yielding rate	45-55%(mango), 90-95%(tomato)
Soluble solid content (fresh juice)	14-16brix (mango ), 4-4.5brix(tomato ), >9brix(guava)
Soluble solid content (Final pulp)	14/28brix (mango ), 28-30/36-38brix(tomato ), >20brix (guava )
Consistency(Bostwick at 20℃)	6-12/3.5-10(mango), 4-8(tomato),3.5-8(guava)
Final product package	Aseptic bag220/1400L//BIB 25L// Can tin 400g/800g
